CO2 Fly Laser Printer CYCJET LC30F
CE certification;
High-quality & stability;
Fly Laser Marking;
Portable & Simple operation
Features
Specifications
Videos
CYCJET LC series fly laser printer uses the original US imported lasers, advanced polarizer system to ensure superior quality and high speed marking output. The entire laser system integrates a touch-screen interface, induction electric parts and lift the bracket. Sophisticated and compact design, it can be easily installed in tight spaces.LC series with high stability, reliability, mainly sued in chemical, food, beverage, pharmaceutical and other marking.
Laser Machine Features
Frame Material
Complete Alum
Laser Device
CO2 Laser
Power
≥30W
Laser Wavelength
10.60μm/9.30μm
Galvanometer Deflection
High Position Dual Dimension Scannning System
Marking Speed
≤12000mm/s
Master Control
High Intergrated Board with 10 Inch Color Touch Screen
Operation System
LINUX high speed marking software
Cooling
Air Cooling(6pcs cooling fans) or Water cooling
Marking Specifications
Focus
140mm
Marking Line Type
Dot Matrix, Bold, Vector all in one(both dot & matrix and vector)
Minimum Line Width
0.015mm
Repeatablity Accurate Positioning
0.003mm
Marking Area
Standard 110mm*110mm(Customized Available)
Marking Height
110mm
Marking Length
Unlimited
Position Mode
Red Light Positioning and Focusing
Number Of Characters
Multi-Line within marking size
Support Type
Typeface
Chinese, English, Arabic, Spanish Font Library
Marking
Number, Logo, Image, Letter, Serial No, System Date & Time Etc.
